| PNC | Part code | Title | Quantity | Modifications | information |
i |
|---|
| 8005 | Radiator Assy | - from 27.08.2012, B-MAX 2012-
|
| 8005 | 1768105 | Radiator Assy | 1.00 | - from 27.08.2012, B-MAX 2012-
|
|
| 8100 | Cap Assy - Overflow Container | - from 27.08.2012, B-MAX 2012-
|
| 8100 | 1301104 | Cap Assy - Radiator | 1.00 | - from 27.08.2012, B-MAX 2012-
|
|
| 8124A | Insulator | - from 27.08.2012, B-MAX 2012-
|
| 8124A | 1535318 | Insulator - Rubber | 2.00 | RH/LH Upper- from 27.08.2012, B-MAX 2012-
|
|
| 8124B | Insulator | - from 27.08.2012, B-MAX 2012-
|
| 8124B | 1746209 | Insulator - Rubber | 2.00 | RH/LH Lower- from 27.08.2012, B-MAX 2012-
|
|
| 8A080 | Tank Assy - Radiator Overflow | - from 27.08.2012, B-MAX 2012-
|
| 8A080 | 1513111 | Tank Assy - Radiator Overflow | 1.00 | - from 27.08.2012, B-MAX 2012-
|
|
| 8C362 | Hose Assy | - from 27.08.2012, B-MAX 2012-
|
| 8C362 | 1791975 | Hose Assy | 1.00 | - from 27.08.2012, B-MAX 2012-
|
|
| 8C455 | Bracket | - from 27.08.2012, B-MAX 2012-
|
| 8C455 | 1763548 | Support - Radiator | 2.00 | RH/LH- from 27.08.2012, B-MAX 2012-
|
|
| 8C607 | Fan And Motor Assy | - from 27.08.2012, B-MAX 2012-
|
| 8C607 | 1843117 | Motor And Fan Assy - Engine Cooling | 1.00 | - from 09.10.2013, B-MAX 2012-, All I3 Engines, With Air Conditioning
- from 27.08.2012, to 09.10.2013, B-MAX 2012-, With Air Conditioning
|
|
| 8C607 | 1843119 | Motor And Fan Assy - Engine Cooling | 1.00 | - from 27.08.2012, B-MAX 2012-, Less Air Conditioning
|
|
| 8L603 | Resistor Assy | - from 27.08.2012, B-MAX 2012-
|
| 8L603 | 1850718 | Resistor Assy | 1.00 | - from 27.08.2012, B-MAX 2012-
|
|
