| PNC | Part code | Title | Quantity | Modifications | information |
i |
|---|
| 5230 | Muffler Assy | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU), 5 Door MAV
- from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU), 5 Door UAV
|
| 5230 | 1847166 | Pipe - Exhaust - Front | 1.00 | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU), 5 Door UAV
|
|
| 5230 | 1847697 | Pipe - Exhaust - Front | 1.00 | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU), 5 Door MAV
|
|
| 5245 | Pipe - Exhaust | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
| 5245 | 1886045 | Pipe - Exhaust | 1.00 | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
|
| 5255 | Pipe - Exhaust | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
| 5255 | 1756588 | Pipe - Exhaust | 1.00 | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
|
| 5A262 | Insulator - Rubber | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
| 5A262 | 1223916 | Insulator - Rubber | 1.00 | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
|
| 5H270 | Catalyst And Particle Filter Assy | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
| 5H270 | 1869341 | Converter Assy | 1.00 | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
|
| 5K291 | Bracket - Exhaust Pipe Mounting | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
| 5K291 | 1751520 | Bracket - Exhaust Pipe Mounting | 1.00 | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
|
| 9450A | Gasket | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
| 9450A | 1879588 | Gasket | 1.00 | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
|
| 9450B | Gasket | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
| 9450B | 1316608 | Gasket | 2.00 | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
|
| 9U501 | Clamp - Exhaust | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
| 9U501 | 1875271 | Clamp - Exhaust | 1.00 | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
|
| HB1 | Bolt | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
| HB1 | 1437840 | Bolt - Hex.Head | 2.00 | M8 X 16MM- from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
|
| HN1 | Nut | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
| HN1 | 6503553 | Nut - Hex. | 4.00 | M10 X 1.5- from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
|
| HN2 | Nut | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
| HN2 | 1404957 | Nut - Locking | 2.00 | M8 X 1.25- from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
|
| HT1 | Stud | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
| HT1 | 1824788 | Stud | 1.00 | M8X22+M8X19- from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
|
| HT2 | Stud | - from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
| HT2 | 1832026 | Stud | 1.00 | M8X19+M8X19- from 13.04.2015, C-MAX/Grand C-MAX 2015- (CEU)
|
|
